- KC-1290D Double-head CO2 Laser Cutting Engraving System
- No.：KC-1290D
- Category：CO2 Laser Cutting Machine
- Evaluation：( 0 ) record
- Hits：2725
Introduction： KC-1290D is equipped with double laser cutting head, the working efficiency will be doubled, the lasers are controlled separately, you can use any one of laser heads to cut or make both two work at the same time.
2- High quality guide rail and high-speed stepper motor ensure the stable, smooth cutting or engraving.
3- Dustproof design,greatly improves the system’s reliability and durability.
4- High quality mirror and focus lens,less laser lost in transmission and have better cutting ability than usual.
5- Water-cooling system with self-protection assures 24-hour working.
|
Model |
KC-1290D |
|
Laser Source |
CO2 Glass Laser Tube |
|
Laser wavelength |
10640 nm |
|
Laser Wattage |
60 W, 80 W or 100 W |
|
Working area: |
1200 x 900 mm |
|
Maximum Table Weight |
21.8 kg |
|
Max. cutting speed |
0-24m/m |
|
Max. engraving speed |
0-48m/m |
|
Max. cutting thickness |
25mm Acrylic sheet |
|
Repeated precision |
±0.01mm |
|
Cooling style |
Water cooling |
|
Power consumption |
1.5 kw |
|
Electrical Requirements |
AC220V ± 5% , 50/60Hz,10 A, Single phase |
|
Environment requirements |
5-35, humidity 30%-80% , no condensation |
|
Supportable formats |
PLT, AI, DXF, BMP, JPG,etc. |
|
Dimension(L x W x H) |
180 x 149 x 112cm |
|
Weight |
270 kg |
Red preview function
Slat working table, better for cutting hard sheet materials such as acrylic .
