- Fiber Laser Welding Machine 2000W
- No.：HDW-2000
- Category：Fiber Laser Welding Machine
- Evaluation：( 0 ) record
- Hits：3141
Introduction： This smart Handheld laser welding machine can effectively solve the problems of slow speed and large deformation of the traditional argon-arc welding. Most similar types of laser welding machine are dominated by water-cooled hand-held welding. Water-cooled hand-held welding uses water as the cooling medium.Mostly focuses on laser 1000W, 1500W,2000W and 3000W laser power.
It’s applicable to welding carbon steel, stainless steel, aluminum, brass , alloy metals, etc.
Widely used in stainless steel engineering welding, metal advertisement welding, sheet metal cabinet welding and large sheet metal structure welding.
1. Fast speed, the laser welding efficiency is about 4 times higher than argon-arc welding.
2. One-time welding forming, smooth welding point, no need extra grinding.
3. With a little heat-affected area,little deformation,the welding seam is good-looking smoothly.
4. Easy to use and master,the operator can become skilled as an professional welder in one day.
5. No consumables, directly use, the protective lens can be used for several weeks.
6. Adopt the high quality fiber laser source which is well-known for long lifetime and good beam quality.
7. Various welding proceses: butt welding,spot welding, stitch welding,seal welding, and overlap welding .
8. Built-in dual-control industrial chiller, protect the whole welding system .
9. With auto wire feeding system, will cover wider gap and enlarge the application.
|
Model No. |
HDW-2000 |
|
Laser Wavelength |
1070nm |
|
Laser power |
1000W/1500W/2000W/3000W |
|
Output laser stability |
≤3% |
|
Laser source lifetime |
≤100 Thousand hours |
|
Beam quality |
1.1 |
|
Working Environment |
Temperature:0-40℃, Humidity: 20%-80% |
|
Working Voltage |
220-240VAC |
|
Cooling Style |
Water cooling |
|
Continuous Working Time |
24 Hours |
|
Output Fiber Length |
8-12M (Can be customized） |
|
Adjustable Power Range |
10-100% |
|
Laser safety level |
Class IV |
|
Packing dimension |
118×76×138 cm |
|
Weight |
N.W: 200kg G.W: 240kg |
